    Undercarriage and mainframe are designed to deliver up to 67-percent longer life. More robust boom-foot base with larger pins strengthens the boom connection. Bushings have been added to the boom tower and boom tip to improve joint integrity and simplify repair.

    Cab Comfort
    • Spacious cab boasts an additional three inches of legroom.
    • Ergonomically correct short-throw pilot levers provide smooth, precise fingertip control with less movement or effort.
    • LED lights are standard for when you need to extend your workday beyond daylight. 14-light LED package plus service and access lights provide outstanding all-around illumination.

    Three productivity modes allow you to adjust the machine to the application.

    • High productivity delivers more power and faster hydraulic response.
    • Power delivers a balance of power, speed, and fuel economy for normal operation.
    • Economy limits top speed and helps save fuel.
    • Larger service bays make it easier to access components, helping ensure daily checks and preventative maintenance get done effortlessly and on schedule.
    • LED lighting illuminates service compartments so you won’t have to fumble around for a flashlight before dawn or after dark.



    Reference Stick size, mm (inches)
    4560 (179)


    Engine Manufacturer
    John Deere
    Engine Model
    PowerTech Plus 9.0 L
    Displacement, ltr (Inches³)
    9 (549)
    Engine Output, kW (hp)
    186 (249)
    Engine Output - Net, kW (hp)
    186 (249)
    Carrier Rollers - Each Side
    Track Rollers - Each Side
    Track Shoe Width, mm (inches)
    700 (28)


    Overall Length, mm (ft/in)
    14810 (48 ft 7 in)
    Transport Height, mm (ft/in)
    3710 (12 ft 2 in)
    Overall Width, mm (ft/in)
    3630 (11 ft 11 in)
    Overall Track Length, mm (ft/in)
    5000 (16 ft 5 in)
    Track Length On Ground, mm (ft/in)
    4060 (13 ft 4 in)
    Tailswing Radius, mm (ft/in)
    3630 (11 ft 11 in)
    Ground Clearance, mm (ft/in)
    790 (2 ft 7 in)
    Width Over Tracks, mm (ft/in)
    3630 (11 ft 11 in)
    Track gauge, mm (ft/in)
    2920 (9 ft 7 in)
    Horizontal Reach, m (ft/in)
    11.07 (36 ft 4 in)
    Dump Height, mm (ft/in)
    10060 (33 ft )


    Fuel Tank, ltr (gallons (US))
    1080 (285)
    Hydraulic Tank, ltr (gallons (US))
    195 (52)


    Ground Bearing Pressure, kPa (PSI)
    74.9 (10.9)
    Slew Torque, kNm (lbf / ft)
    120 (88507)
    Travel Speed, kph (mph)
    4.2 (2.6)
    Lift capacity at max reach, kg (lbs)
    7280 (16040)
    Pump Type
    Variable Axial Piston
    Pump Flow, lt/min (gallons (US) / min)
    248 (65.5) x 2
    Relief Pressure, kPa (PSI)
    34300 (4975)
    Boost Pressure, kPa (PSI)
    38000 (5511)


    Operating Weight, kg (lbs)
    42579 (93870)
