    • More dependable electrical architecture simplifies wiring harnesses and reduces the number of electrical connectors, fuses, and relays by approximately 25 percent.
    • Undercarriage X-frames and upper-frame structures have been improved to deliver significantly longer life than previous models.
    • Hydraulically driven, variable-speed fan runs only as needed, conserving power and fuel. Reversing option automatically reverses airflow to eject debris from the cooler cores, decreasing cooler-maintenance frequency.
    • Larger, more durable, and higher-capacity coolers along with improved airflow help reduce hydraulic operating temperatures, for maximum component life.
    • Larger-diameter rollers with polished shafts and improved seals extend wear life, while reducing downtime and maintenance costs.
    Cab Comfort
    • Roomier cab boasts an additional three inches of legroom.
    • Ergonomically correct short-throw pilot levers provide smooth, precise fingertip control with less movement or effort.
    Simple Maintenance
    • Half-level hydraulic-control system reduces fuel consumption by three to five percent, depending on application.
    • Ground-level servicing and conveniently located filters, fluid-fill locations, and grease points help ease daily checks and preventative maintenance.



    Reference Stick size, mm (inches)
    4100 (161)


    Engine Manufacturer
    John Deere
    Engine Model
    PowerTech PVS 6.8 L
    Displacement, ltr (InchesĀ³)
    6.8 (415)
    Engine Output, kW (hp)
    145 (194)
    Engine Output - Net, kW (hp)
    145 (194)
    Carrier Rollers - Each Side
    Track Rollers - Each Side
    Track Shoe Width, mm (inches)
    700 (28)


    Overall Length, mm (ft/in)
    14150 (46 ft 5 in)
    Transport Height, mm (ft/in)
    3760 (12 ft 4 in)
    Overall Width, mm (ft/in)
    3530 (11 ft 7 in)
    Overall Track Length, mm (ft/in)
    5030 (16 ft 6 in)
    Track Length On Ground, mm (ft/in)
    4060 (13 ft 4 in)
    Tailswing Radius, mm (ft/in)
    3150 (10 ft 4 in)
    Ground Clearance, mm (ft/in)
    760 (2 ft 6 in)
    Width Over Tracks, mm (ft/in)
    3530 (11 ft 7 in)
    Track gauge, mm (ft/in)
    2790 (9 ft 2 in)
    Horizontal Reach, m (ft/in)
    11.71 (38 ft 5 in)
    Dump Height, mm (ft/in)
    8790 (28 ft 10 in)


    Fuel Tank, ltr (gallons (US))
    800 (211)
    Hydraulic Tank, ltr (gallons (US))
    136 (36)


    Ground Bearing Pressure, kPa (PSI)
    61.3 (8.89)
    Slew Torque, kNm (lbf / ft)
    107.869 (79560)
    Travel Speed, kph (mph)
    3.9 (2.4)
    Lift capacity at max reach, kg (lbs)
    4780 (10540)
    Pump Type
    Variable Axial Piston
    Pump Flow, lt/min (gallons (US) / min)
    248 (65.5) x 2
    Relief Pressure, kPa (PSI)
    34300 (4975)
    Boost Pressure, kPa (PSI)
    38000 (5511)


    Operating Weight, kg (lbs)
    36252 (79922)
