    Features

    Intelligent Boom Control
    • A first in the harvester category, IBC provides operators with increased accuracy and productivity — bringing harvester capabilities to a whole new level.
    • With IBC, the operator controls only the harvester head while the system takes care of the boom's movement. Designed specifically to suit the harvester work cycle, the boom's movement and operation automatically adjust as the boom is taken to a tree and when the tree is in the grapple. IBC enables precise working and the selection of the correct working methods.
    Twin-Pump Hydraulics
    • Twin-pump hydraulic system that delivers simultaneous power to the boom and harvester head.
    Standard Intelligent Control
    • Processing Power Control (PPC) lowers operating costs and increases productivity by five to 15 percent by balancing processing power and fuel economy in a variety of logging applications.
    Agile and Productive
    • Choose from compact six- or eight-wheeled options.
    Updated Windows

    RENCRAFT® Super Hard Coat polycarbonate windows are scratch resistant, tolerant of cleaning agents, and enhance optic quality. These windows comply with the ISO 21876 saw-chain shot-testing standard, proving their durability. Plus, due to their almost 50-percent thicker material than previous windows, the cab is better insulated, resulting in a quieter work environment.

    Specifications


    DESCRIPTION

    Crane Model
    CH7

    DRIVELINE

    Engine Manufacturer
    John Deere
    Engine Model
    6090HTJ
    Emission Rating
    Tier 3
    Rated Speed, rpm
    1900
    Engine Output, kW (hp)
    190 (255)
    Engine Torque, Nm (lbf / ft)
    1250 (922)
    Drive Configuration
    6 x 6
    Transmission Type
    Hydrostatic-Mechanical
    Std tire size front
    26.5
    Std tire size rear
    34

    DIMENSIONS

    Base Carrier Length, mm (inches)
    7697 (303)
    Transport Height, mm (inches)
    3810 (150)
    Overall Width, mm (inches)
    2746 (108.12)
    Wheelbase, mm (inches)
    4170 (164.16)
    Ground Clearance, mm (inches)
    654 (25.7)
    Horizontal Reach, m (ft/in)
    8.6 (28 ft 2 in)

    CAPACITIES

    Fuel Tank, ltr (gallons (US))
    450 (119)
    Hydraulic Tank, ltr (gallons (US))
    300 (79)
    Number Of Alternators
    1
    Reference Harvesting Head
    H480C
    Felling Diameter, mm (inches)
    710 (28)
    Delimbing Diameter, mm (inches)
    680 (26.8)
    Delimbing Feed Rate, m/sec (ft/sec)
    5.3 (17.4)
    Delimbing Feed Force, kN (lbf)
    30 (6744)
    Travel Speed, kph (mph)
    22 (13.7)
    System Voltage, V
    24
    Pump Capacity, cm³ (Inches³)
    190 (12)

    WEIGHTS

    Operating Weight, kg (lbs)
    22200 (48943)
    Weight - With Reference Head, kg (lbs)
    22200 (48943)
    Weight - Without Reference Head, kg (lbs)
    20960 (46209)
